The Altelix DIN Rail Mountable Turbo Heater Kits provide a simple way to add heat for a wide range of applications. These DIN rail mountable heater kits can be used to retrofit existing equipment enclosures, equipment cabinets or as well as applications that require a heater to be installed.
Thermostat Controlled with 60mm Fan
The Safe Touch heaters in these kits generate a high air-current of warm air. The internal design of these heaters help reduce the surface temperatures on the accessible sides of the housing. A 60mm fan attached to the face of the heater provides increased heat dispersion. The included thermostat turns the heater and fan on when the internal temperature reaches 41°F (5°C) and turns off when it rises to 59°F (15°C).
Easy to Install - No Wiring Required
Installing these heater kits is simple since no electrical wiring is required. Simply mount the heater to a 35mm Top Hat DIN Rail (sold separately) and plug the pre-wired 2.5 foot power cord into a 120VAC power outlet.
Available in 50W or 100W
This Turbo Heater kit is available in either 50W or 100W power.
DIN Rail Mountable
The backside of these heaters feature an integral DIN rail clip allowing the heater to be attached to standard 35mm Top Hat DIN Rails. See the Accessories Section for available DIN Rail kits.
Technical Specifications
| Model Number | NHH050WFAC-DIN-KIT | NHH100WFAC-DIN-KIT |
| Heater Power | 50W | 100W |
| Operating Voltage | 110-250 VAC/VDC | 110-250 VAC/VDC |
| Heating Element | PTC Resistor | PTC Resistor |
| Fan Type | 120VAC 60mm | 120VAC 60mm |
| Mounting | 35mm DIN Rail | 35mm DIN Rail |
| Mounting Position | Vertical | Vertical |
| Heater Turn-On Temperature | 41°F (5°C) ±9°F | 41°F (5°C) ±9°F |
| Heater Turn-Off Temperature | 59°F (15°C) ±9°F | 59°F (15°C) ±9°F |
| Power Cord Length | 2.5 Feet (762mm) | 2.5 Feet (762mm) |
| Dimensions | 2.4 x 7.5 x 3.4 in. (60 x 190.5 x 86 mm) | 2.4 x 9.0 x 3.4 in. (60 x 228.6 x 86 mm) |
| Weight | 1.26 lbs. (0.57 kg) | 1.61 lbs. (0.73 kg) |
Downloads
For 35mm DIN Rail Kits for Altelix enclosures, click the ACCESSORIES and ADD-ONS button.
