Altelix 10x8x6 Fiberglass Weatherproof NEMA 4X Enclosure with Blank Aluminum Equipment Mounting Plate

SKU:
NF100806P
Availability:
Same Day Shipping
  • Altelix 10x8x6 Inch Fiberglass Weatherproof NEMA 4X Enclosure with Aluminum Equipment Mounting Plate
  • Altelix 10x8x6 Inch Fiberglass Weatherproof NEMA 4X Enclosure with Aluminum Equipment Mounting Plate
  • Altelix 10x8x6 Inch Fiberglass Weatherproof NEMA 4X Enclosure with Aluminum Equipment Mounting Plate
  • Altelix 10x8x6 Inch Fiberglass Weatherproof NEMA 4X Enclosure with Aluminum Equipment Mounting Plate
  • Altelix 10x8x6 Inch Fiberglass Weatherproof NEMA 4X Enclosure with Aluminum Equipment Mounting Plate
  • Altelix 10x8x6 Inch Fiberglass Weatherproof NEMA 4X Enclosure with Aluminum Equipment Mounting Plate
  • Scale Reference
Your Price: $99.99

Get simple modifications in only 5 days! Click to learn more.

For customization and volume pricing inquiries please Click Here to email us at sales@altelix.com

Description

Features
  • Includes Easy to Drill Blank Aluminum Equipment Mounting Plate
  • Water Resistant JIC Enclosure Design with Gasketed Lid
  • Meets NEMA 1, 2, 4, 4X, 12, 13, and IP65, IP66
  • Stainless Steel Hinge and Quick Release Latches with Padlock Hasps
  • Fiberglass Reinforced Polyester, FRP
  • Weatherproof, UV Stable and Highly Corrosion Resistant
  • Includes Stainless Steel Mounting Feet
  • RF Transparent and Non-Conductive
  • Pole Mounting Kit Available
Applications
  • Harsh Environments
  • WiFi Enclosure
  • RFID Reader Enclosure
  • IoT Sensors
  • SCADA Remote Terminal Unit
  • Security and Surveillance Systems
  • Solar Equipment Enclosure
  • Outdoor Use of Indoor Equipment
  • Protection from Vandalism
  • Concealment of Electronic Equipment
  • Building Automation Controls
  • Industrial Controls Enclosure



Extreme Protection Built to Last

The Altelix NF100806P NEMA 4X Weatherproof Enclosure is ideal for protecting equipment from harsh environments and tampering. This rugged NEMA box is molded from durable and UV resistant fiberglass reinforced polyester (FRP) with a UL94-5V flame rating. It features a gasketed door with stainless steel continuous hinge and stainless steel quick release latches with padlock hasps.

This JIC style enclosure is dent-proof, corrosion resistant and UV stable. The FRP material is non-conductive and RF transparent. It is suitable for use in the harshest outdoor environments. It can be drilled and modified by the installer to suit unique site requirements.

Aluminum Equipment Plate
This model features an easy to drill, aluminum equipment mounting plate. The enclosure and plate can be drilled and modified by the installer to suit unique site requirements.

Mounting
Stainless steel brackets are included for secure wall mounting. Optional flange and pole mounting kits are available (see accessories above).

Larger Size Available
For applications requiring additional interior space, the NF10 Series enclosures are available in a larger size. The NF100808 enclosures feature an extended lid for increased equipment clearance. Click Here for more information.

Customization
We offer custom enclosures for WiFi equipment, DIN Mount Industrial Controls, Telephone Call Boxes, IP Phones, Security & Safety, Building Automation and More. Options include equipment mounting plates, DIN rails, AC/DC power, vents, cooling fans, heaters. We also offer full customization, engineering and on-site CNC machining of enclosures and associated equipment, all with quick turnaround time. Please contact us with your unique requirements.

Technical Specifications

Material Fiberglass Reinforced Polyester
Color Grey
Outer Dimensions 11.7 x 9.8 x 6.8 In. (297 x 250 x 173 mm)
Inner Dimensions* 9.0 x 7.0 x 5.5 In. (228 x 177 x 139 mm)
Mounting Plate Material 0.10 in. (2.5mm) Aluminum
Mounting Plate Dimensions 9.1 x 7.4 in. (231 x 188 mm)
Weight 6.2 lbs. (2.8 kg)
Ratings NEMA Type 4, 4X / IP66
Industry Certifications CE
*Interior dimensions represent space available for equipment. See drawing for additional details.




NEMA Ratings and IP Equivalency Chart
This chart provides the different NEMA ratings and their definitions as well as the IP equivalents and definitions.

  Same Day Shipping - Click Here for details.



Need a pole mount kit? Click the ADD-ONS and ACCESSORIES button below to see all the available accessories for this enclosure.
