The Altelix Weatherproof Emergency Cell Phone Enclosure is ideal for deploying emergency cell phones in outdoor and remote locations without access to power or wired landlines.
New Life for Old Cell Phones
Most old cell phones which are no longer subscribed to or supported by a specific carrier can still call 911 services. This makes them ideal as emergency only phones. The Altelix Emergency Cell Phone Enclosure is designed for just that purpose.
Easy to Install
Since the Altelix TBP uses Power-over-Ethernet (PoE) to provide power to the cell phone, this enclosure is ideal for locations with no power available. Simply run an Ethernet cable (not included) from the internal PoE adapter inside the enclosure to any device that provides PoE power, such as network switch or a PoE power injector installed at the location where power is provided. Inside the enclosure a magnetic cell phone mount is provided for use with any cell phone. A cable is provided from the PoE adapter to charge the cell phone. This charging cable is available with either a USB-C or Micro USB connector.
Rugged Construction for Outdoor Use
This durable NEMA 3X enclosure is molded out of UV resistant PC+ABS, a high tech blend of polycarbonate and ABS which combines the best qualities of both into a single material. PC+ABS enclosures maintain high toughness, durability and dimensional stability even at extreme cold and hot temperatures. The door is gasketed for use in dusty or wet areas..
Mounting
The enclosure can be wall mounted using the included anchors. The mounting hardware is concealed within the enclosure for a finished appearance and enhanced security. An optional pole mount kit is also available.
Emergency Phone Label
This enclosure features a red and white weatherproof UV resistant Emergency Phone label on the door.
Customization
Customization is available to meet your specific requirements. Please Contact Us for more information.
Technical Specifications
| Material | PC+ABS Polycarbonate / ABS Blend |
| Available Colors | Gray, Light Ivory, OD Green |
| Outer Dimensions | 13.4 x 11.5 x 5.0 Inches (340 x 293 x 127 mm) |
| Inner Dimensions | 10.5 x 8.0 x 3.7 Inches (266 x 203 x 94 mm) |
| Equipment Mounting Plate Material | 0.25 in. (6.4mm) PVC |
| Charging Cable Connectors | USB-C or Micro USB |
| Weight | 4.2 lbs. (1.9 kg) |
| Ratings | NEMA Type 1, 2, 3, 3R, 3S, 3X / IP55 |
| Flame Rating | Meets UL94-V0 |
 |
NEMA Ratings and IP Equivalency Chart |
Downloads
Same Day Shipping On Select Models, See Below
Availability:
TBP14G-1 (OD Green) - Usually Ships in 1 to 2 Business Days
TBP14T-1 (Light Ivory) - Usually Ships in 1 to 2 Business Days
Need a pole mount kit? Click on ADD TO CART below to see all the available accessories for this enclosure.
